NAT-MCHFull-size base MCH module for MicroTCA shelves
- Manufacturer
- Configurations
- 3 available configurations
The MCH is the module that turns a set of AMC boards into a MicroTCA system: it gathers slot handling, coordinates module power-up and routes traffic on the backplane. NAT-MCH plays this role in the base configuration, in full height format.
On the front panel diagnostics are immediate: the indicators report the state of the AMC modules, of the cooling units and of the power modules, so that a fault can be located without connecting a terminal. The board states support for the AMC.0, AMC.1, AMC.2 and AMC.4 profiles.
At a glance
- Processor: NXP Coldfire MCF54452 CPU @266MHz
- Board function: MCH (carrier hub)
- Architecture standard: AMC.2
- Form factor: Single full-size
Technical specifications
| Processor | NXP Coldfire MCF54452 CPU @266MHz |
|---|
| Board function | MCH (carrier hub) |
|---|---|
| Architecture standard | AMC.2AMC.4AMCAMC.1MTCA |
| Form factor | Single full-size |
| Bus interface | 12 AMCs, x1-x4 each; PICMG AMC.1 R1.0 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
The order codes of this family: the sheet applies to all of them, the detail of each configuration is in the datasheet.
| Configuration (PN) |
|---|
| NAT-MCH-Base12-GbE |
| NAT-MCH-Base12-GbE-D.3_2024 |
| NAT-MCH-Base12-GbE-D.3_2025 |
