MicroTCA Blades & Modules (MTCA.0)
AMC215AMC.2 module with two 10GbE ports on SFP+ and XAUI link
- Manufacturer
AMC215 is an AdvancedMC module conforming to AMC.2 that exposes two 10GbE interfaces on SFP+ cages, bringing ten gigabit connectivity to the front panel of an AdvancedTCA or MicroTCA shelf.
Towards the backplane the module uses the XAUI lanes. The SFP+ optics are chosen at order time among 10GBASE-SR, 10GBASE-LRM and 10GBASE-LR, or the module can be supplied without a transceiver. The front panel comes in mid or full height.
At a glance
- Board function: Ethernet
- Architecture standard: AMC.2
- Power consumption: 5 W
Technical specifications
| Ethernet ports | 10 Gb/s per port |
|---|
| Board function | Ethernet |
|---|---|
| Architecture standard | AMC.2AMC |
| Bus interface | Dual SFP+ Connectors |
| IPMI management | 2.0 |
| Hot-swap | sì(ejector-handle) |
| Power consumption | 5 W |
|---|
| Dimensions | 73.5 × 180.6 mm |
|---|
| Storage temperature | -40–90 °C |
|---|
| Certifications | FCCCEUL |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
