MicroTCA Blades & Modules (MTCA.0)
AMC204AMC module with four Gigabit Ethernet ports on RJ-45
- Manufacturer
AMC204 adds four Gigabit Ethernet ports to a MicroTCA shelf, working at 10/100/1000 Mbps over copper with RJ-45 connectors on the front panel; IP, TCP and UDP checksum offload relieves the CPU of the compute module.
Conformance to AMC.1 and AMC.2 allows traffic to be routed towards the fabric or towards the front panel. Stated draw is 8 W, MTBF 279,000 hours and storage temperature runs from -40 to 90 °C.
At a glance
- Board function: Ethernet
- Architecture standard: AMC.2
- Power consumption: 8 W
Technical specifications
| Board function | Ethernet |
|---|---|
| Architecture standard | AMC.2AMC.1AMC |
| Bus interface | x8 |
| IPMI management | 2.0 |
| Hot-swap | sì(ejector-handle) |
| Power consumption | 8 W |
|---|
| Dimensions | 73.5 × 180.6 mm |
|---|
| Storage temperature | -40–90 °C |
|---|---|
| MTBF | 279000 h |
| Certifications | FCCCEUL |
|---|
| Operating systems | LinuxWindowsSolarisVxWorks |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
