AMC095AMC.0 and AMC.1 module with 16 TTL and voltage inputs
- Manufacturer
AMC095 gathers eight TTL/CMOS channels and eight voltage channels from 0 to 10 V on a single compact module, conforming both to AMC.0 and to AMC.1 and therefore fitting MicroTCA shelves of different generations.
State change detection is configurable on rising edge, falling edge or by level, while the input supply accepts from 10 to 38 V with a peak of 45 V. Stated draw is 3 W and storage temperature runs from -40 to 85 °C.
At a glance
- Board function: I/O
- Architecture standard: AMC.1
- Form factor: Single compact-size
- Power consumption: 3 W
Technical specifications
| Board function | I/O |
|---|---|
| Architecture standard | AMC.1AMC |
| Form factor | Single compact-size |
| Bus interface | x451-pin Micro DIN connector |
| IPMI management | 2.0 |
| Hot-swap | sì(ejector-handle) |
| Power consumption | 3 W |
|---|
| Storage temperature | -40–85 °C |
|---|
| Certifications | CEFCCUL |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
