| Model | Size | Processor | Connection | Front I/O | Resolution | Description |
|---|---|---|---|---|---|---|
| AMC342 | Single Width
Mid-Size |
ATI 512 MB GDDR3 memory | x4 or x8 PCI-Express | Dual DVI(HDMI), VGA | Up to 3840 x 2400 @ 60 Hz | The AMC342 is VadaTech third generation AMC graphic module. Designed to meet the high performance real-world graphics needs of Military, Industrial and Telecom applications. |
| AMC343 | Single Width
Mid-Size |
ATI 1GB GDDR5 memory | x4 or x8 PCI-Express Gen2 | 2 x High density connector
1 x HDC to Hex Link DVI |
Up to 2560 x 1600 @ 60 Hz | AMC 6 Channel DVI/VGA with HDMI Graphics Module |
| AMC349 | Single Width
Mid-Size |
SM750 16 MB of DDR memory | x1 | DVI | Up to 1920 x 1400 | AMC Single Channel DVI/VGA Graphics Module |
| AMC345 | Single Width
Mid-Size |
ATI 512 MB GDDR3 memory | x4 or x8 PCI-Express | Dual DVI, VGA | Up to 3840 x 2400 | The AMC345 is VadaTech third generation AMC graphic module. Designed to meet the high performance real-world graphics needs of Medical and Military applications. |
| AMC900 | Single Width
Mid-Size |
– | – | Dual VGA to dual RGB | Up to 1600 x 1200 @ 60Hz | The AMC900 is a AMC form factor module that has dual VGA analog video receiver inputs |
| AMC901 | Single Width
Mid-Size |
– | – | Dual Micro DB-15 | Up to 1600 x 1200 @ 60Hz | RGsB Video Driver |
