AIE-PN33/43: Embedded fanless PC with NVIDIA Jetson Orin NX

April 2024

AIE-PN33/43: Embedded fanless PC with NVIDIA Jetson Orin NX

Aetina Corporation introduces AIE-PN33/43, the new fanless Edge Computing platform based on NVIDIA Jetson Orin NX and suitable for all those AI applications in smart city and smart agriculture where maintenance, performance and reliability are of crucial importance. AIE-PN33/43 integrates 8GB or 16GB Jetson Orin NX, up to 5 times more powerful than the previous generation, and offers up to 100 TOPS, 1024 NVIDIA Ampere cores and 32 Tensor cores, thus setting a new standard for mainstream edge AI devices. AIE-PN33/43 offers extensive I/O including two GbE LANs, up to four GbE POEs, two USB 3.2 Gen2, one USB Type C (OTG), two COMs, one HDMI and one CANBus. In addition, the AIE-PN33/43 can be equipped with WIFI/BT and LTE/5G via M.2 expansion slots, while 128GB of storage is already integrated via an M.2 NVMe module. The embedded platform AIE-PN33/43 has dimensions of 270x195x80 mm and supports wall and DIN-RAIL mounting, an operating temperature from -25°C to +55°C and a 12-24VDC power supply for industrial applications.

Datasheet

AIE-PN33/43: Embedded fanless PC with NVIDIA Jetson Orin NX2024-04-22T17:03:15+02:00

PPC2-CW15-EHL: 15.6″ Full HD Industrial Panel PC with Intel Celeron J6413 Elkhart Lake CPU

April 2024

PPC2-CW15-EHL: 15.6″ Full HD Industrial Panel PC with Intel Celeron J6413 Elkhart Lake CPU

IEI Technology introduces PPC2-CW15-EHL, the new fanless Full HD 15.6″ (16:9) Panel PC based on the Intel Celeron J6413 processor with Elkhart Lake architecture. PPC2-CW15-EHL Panel PC is available with a 10-point multitouch PCAP touchscreen, support for use with gloves, and anti-glare coating with IP65 front panel protection for exposure to dust and liquids. PPC2-CW15-EHL has 8GB of RAM pre-installed and numerous I/O interfaces including five COM, two USB 3.2 Gen.2, four USB 2.0, two 2.5GbE and one HDMI. On the storage side, PPC2-CW15-EHL offers a bay for a 2.5-inch HDD/SSD and a socket for an additional M.2 2242 M-Key SSD on PCIe Gen3 x2 BUS for high-speed data transfer. PPC2-CW15-EHL offers 12-24VDC power supply via jack and terminal block (2-pin), extended operation from -10°C to +60°C, and can be used in a wide range of applications such as retail, operator machines, process control and industrial automation.

Datasheet

PPC2-CW15-EHL: 15.6″ Full HD Industrial Panel PC with Intel Celeron J6413 Elkhart Lake CPU2024-04-22T17:03:24+02:00

Express-RLP: COM Express Type 6 with Intel Core 13th Gen Raptor Lake-P



April 2024

Express-RLP: COM Express Type 6 with Intel Core 13th Gen Raptor Lake-P

ADLINK introduces Express-RLP, the new COM-Express Type 6 module equipped with 13th generation processors and based on the Raptor Lake-P platform. The hybrid architecture with P-core (performance) and E-core (efficiency) ensures high performance together with low power consumption. The high scalability of integrable CPUs, from i3 up to i7, makes Express-RLP an versatile solution that can be easily integrated to realise customised embedded boards. The Express-RLP module’s managed RAM memory is expandable up to a maximum of 64GB DDR5 on dual SODIMM sockets, while the video compartment is managed so as to guarantee the simultaneous and independent connection of up to four of the available ports: DisplayPort, HDMI, LVDS, eDP, VGA. Express-RLP also features 4x USB 3.2 ports, 4x USB 2.0, 2x SATA 6Gb/s, 2x UART, 8x GPIO, and support for NVMe-type SSDs. Express-RLP is available in a standard version with an operating temperature from 0°C to +60°C or in an Extreme Rugged version with an extended operating temperature from -40°C to +85°C.

Datasheet

Express-RLP: COM Express Type 6 with Intel Core 13th Gen Raptor Lake-P2024-04-22T17:03:30+02:00

XRS 3U S8: Extreme Rugged Edge Server with 4th/5th generation Intel Xeon Scalable Processors

April 2024

XRS 3U S8: Extreme Rugged Edge Server with 4th/5th generation Intel Xeon Scalable Processors

Goma Elettronica SpA announces XRS 3U S8, the new family of Extreme Rugged Servers optimized for Edge applications, where they offer superior robustness and high-performance computing technology. The XRS 3U S8 Series is powered by single or dual socket 5th/4th Gen Intel Xeon Scalable Processors that bring significant advancements in core counts, memory capacities, AI and machine learning acceleration, advanced security features, and PCIe 4.0/5.0 support, establishing the series as a foundational element for the future of high-performance and AI-driven Edge applications. This series features a 3U milled aluminium chassis providing unmatched resistance and torsional strength essential for Edge computing sites, which often face extreme operational demands. It offers configurations with depths of 470mm or 550mm for standard or round MIL-grade I/O connectors and is capable of accommodating up to six full-height, full-length PCIe boards, and designed for high density storage with the capacity for up to twelve removable SSDs. Qualified according to MIL-STD-810G for temperature, shocks, and vibrations, and conforming to MIL-STD-461 for EMI/EMC, the XRS Series Extreme Rugged Edge Servers are robustly built to meet the stringent requirements of Edge computing environments.

Datasheet

XRS 3U S8: Extreme Rugged Edge Server with 4th/5th generation Intel Xeon Scalable Processors2024-04-22T17:03:37+02:00

Talon RGD2443W: 24-inch Rugged Monitor

April 2024

Talon RGD2443W: 24-inch Rugged Monitor

Eizo Rugged Solutions introduces Talon RGD2443W, the new 24-inch 4K UHD rugged monitor in 16:9 aspect ratio (3840 x 2160) designed for harsh environments. In fact, Talon RGD2443W is ideal for military environments, where devices must be able to operate in harsh environments without sacrificing performance. Talon RGD2443W is IP65 on both front and rear (excluding connectors), while the panel features a capacitive touch screen, anti-glare and anti-fingerprint coating. In terms of I/O, Talon RGD2443W has two Display Ports, two HDMI and USB, RS-232C and RS-485 communication interfaces. This monitor also has -20 /+55°C operating temperature and 18-36VDC power supply, which is also available in AC upon request. On every Talon monitor, EIZO performs vibration, shock, humidity, decompression and extreme temperature testing at its own in-house durability test center to meet MIL-STD-810 and MIL-STD-461 standards. Talon RGD2443W features several optionals including ‘EIZO LCD Flicker Compensation’ (E-LFC), ‘Image Enhancement Technology’ and the addition of handles, while options and variants such as EMI filters, NVIS screens, custom connectors and special formats can be easily realised upon request.

Datasheet

Talon RGD2443W: 24-inch Rugged Monitor2024-04-23T09:49:10+02:00
