Industrial PCs with Motherboard
GO-481-SAS-IPC4U rack chassis with fourteen removable drive trays
- Manufacturer
GO-481-SAS is a four rack unit chassis in cold rolled steel intended for storage systems installed in a cabinet, 650 mm deep.
The front, closed by a removable door with thumb screws, holds the 3.5" removable drive trays, an optical drive and a slim unit. The rear bay accepts an N+1 redundant power supply, while the front LEDs signal power, drive activity, fans, temperature and network. The buttons include power, system reset and buzzer reset.
At a glance
- Storage: 3x backplane x 4 dischi SAS, 1 connettore SFF-8643 | 12x Swappable Tray SAS 12 Gbps | 2x Swappable Tray SAS 6 Gbps
- Motherboard form factor: E-ATX
- Number of slots: 7
- Mounting: Rack Mount
- Cooling: Fan (active)
Technical specifications
| Storage | 3x backplane x 4 dischi SAS, 1 connettore SFF-8643 | 12x Swappable Tray SAS 12 Gbps | 2x Swappable Tray SAS 6 Gbps |
|---|
| Other I/O | Fronte: Porta drive rimovibile con viti imperdibili, 2 x USB · Retro: Alloggiamento per 7 bracket full height |
|---|
| Motherboard form factor | E-ATX |
|---|---|
| Number of slots | 7 |
| PSU power | 950 W(optional) |
|---|
| Rack units | 4 |
|---|---|
| Mounting | Rack Mount |
| Chassis material | Acciaio pre-zincato |
| Chassis color | Nero o altri colori su richiesta |
| Dimensions | Chassis 4U - 483 x 177 x 650 mm |
| Front panel buttons | Power On/Off, System Reset, Buzzer reset |
| Cooling | Fan (active) |
|---|---|
| Storage temperature | -20–70 |
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
