Industrial PCs with Motherboard
GO-351-IPC3U rack chassis with PWM fans for ATX motherboards
- Manufacturer
GO-351-PF is a three rack unit chassis in pre-galvanized steel for 19 inch cabinets, 400 mm deep.
The rear houses seven low profile brackets around an ATX motherboard up to 12″ × 9.6″; the front carries a 5.25″ drive, three 3.5″ drives, two USB and the power, drive and network LEDs. Two PWM controlled 80 mm fans cool the interior, with another two of 60 mm on request.
At a glance
- Storage: 1 x 5.25” + 1 x 3.5” + 2 x 3.5”
- Motherboard form factor: ATX
- Number of slots: 7
- Mounting: Rack Mount
- Cooling: Fan (active)
Technical specifications
| Storage | 1 x 5.25” + 1 x 3.5” + 2 x 3.5” |
|---|
| Other I/O | Fronte: 2 x USB · Retro: Alloggiamento per 7 bracket full height |
|---|
| Motherboard form factor | ATX |
|---|---|
| Number of slots | 7 |
| Rack units | 3 |
|---|---|
| Mounting | Rack Mount |
| Chassis material | Acciaio pre-zincato |
| Chassis color | Nero, beige o altri colori su richiesta |
| Dimensions | Chassis 3U - 483 x 133 x 400 mm |
| Front panel buttons | Power On/Off Momentary (Rocker) e System Reset |
| Cooling | Fan (active) |
|---|---|
| Storage temperature | -20–70 |
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
