Industrial Servers with Motherboard
GO-261-SRV2U industrial server with sixteen 2.5″ hot-swap bays
- Manufacturer
GO-261 is a 2U chassis for ATX motherboards up to 12″ × 13″, intended for 19″ rack cabinets: pre-galvanized steel chassis of 483 × 88 × 580 mm.
The front carries sixteen 2.5″ hot-swap trays, an internal drive, two USB and a removable air filter, while the rear houses six full size brackets; four 80 mm PWM fans cool from the front and every unit goes through climatic burn-in and leaves with its acceptance Test Report. GOMA configures it for the application.
At a glance
- Motherboard form factor: E-ATX
- Number of slots: 6
- Mounting: Rack Mount
- Cooling: Fan (active)
- Operating temperature: 0~45
Technical specifications
| Storage | 16x Hot Swap 2.5” Drive Trays, 1x 2.5” HDD | and 1x CD Rom Slim (optional) |
|---|
| Other I/O | Front: Drive door with captive screws, 2 x USB · Rear: Bay for 6 full height brackets |
|---|
| Motherboard form factor | E-ATX |
|---|---|
| Number of slots | 6 |
| Rack units | 2 |
|---|---|
| Mounting | Rack Mount |
| Chassis material | Pre-galvanized steel |
| Dimensions | Chassis 2U - 483 x 88 x 580 mm |
| Chassis color | Black, beige or other colors on request |
| Front panel buttons | Power On/Off and System Reset |
| Cooling | Fan (active) |
|---|---|
| Storage temperature | -20–70 |
| Air filter | front-removable air filter |
| Operating temperature | 0~45 |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
