RCO-1000-EHL-30-2PFanless embedded computer with Intel Atom X6425E (Elkhart Lake) and dual PoE
- Manufacturer
- Configurations
- 1 available configurations
RCO-1000-EHL-30-2P is a fanless x86 mini computer in an extruded aluminium chassis, 150 x 105 x 83 mm and 1.2 kg, for machine-side cabinets, IIoT gateways and locations where the air is dusty and maintenance is infrequent.
The Elkhart Lake SoC drives two DisplayPort 1.4 outputs in independent dual display up to 4096 x 2160@60Hz, while the I/O stays reconfigurable: three Universal I/O brackets accept optional COM, USB, HDMI 2.0 or DP modules with isolated DIO, and the M.2 B key slot hosts a 4G or 5G module with two external SIMs. A system that adapts to the field, not a closed box.
Also available in the RCO-1000-X6425E-30-2P-P configuration, with power supply included.
At a glance
- Dual PoE IEEE 802.3af, 30 W total
- 9–36 VDC input, AT/ATX mode
- DDR4 SODIMM up to 32 GB
- Shock according to MIL-STD-810H
- TPM 2.0 onboard
Technical specifications
| CPU generation | Elkhart Lake |
|---|---|
| Processor | Intel® Atom® X6425E |
| Chipset | SoC |
| Graphics | Intel® UHD Graphics |
| AI module | Hailo-8 |
| Memory | 1× SODIMM DDR4 260-pin 2400/2667/3200 MT/s |
|---|---|
| RAM type | DDR4 |
| Maximum RAM | 32 GB |
| Storage | 1× Internal 2.5" SATA HDD Bay (support H=9.5 mm) |
|---|
| Video outputs | 2× DisplayPort 1.4, DP++ (4096× 2160@60Hz) |
|---|
| Ethernet ports | 2.5 GbE2: Intel I225 (Support Wake-on-LAN and PXE) 1 GbE1: Intel I210 (Support Wake-on-LAN and PXE) |
|---|---|
| USB ports | 3x USB 3.2 Gen 2 (10 Gbps) 1x USB 2.0 |
| Serial interfaces | 2× RS-232/422/485 |
| Audio | 1× Mic-in, 1× Line-out |
| Digital I/O | 1× DisplayPort and 1× DIO(4 in / 4 out, Isolated)(optional) |
| CAN bus | 2× CAN 2.0 A/B 2-pin Internal header |
| PoE | 2× PoE. Max. up to 30W |
| Wireless | 4G/LTE5GWi-Fi 6 (802.11ax)Bluetooth(optional)Wi-Fi(optional) |
|---|
| Expansion | 3× Universal I/O Bracket (By mini PCIe interface, Proprietary Module)1-Port DP 1.4 and DIO (4 in / 4 out, Isolated), Support 1× Universal Slot Only(optional)1-Port HDMI 2.0, Support 1× Universal Slot Only(optional)2-port COM module with Super I/O Chipset, Support 2× Universal Slot Only(optional)4-Port USB module with USB hub, Support 1× Universal Slot Only(optional) |
|---|
| Supply voltage | 9–36 V |
|---|---|
| Battery / UPS | 1× Internal CMOS Battery Cable |
| Mounting | DIN Rail Mount(optional)VESA Mount(optional)Wall Mount(optional) |
|---|---|
| Dimensions | 150 (W) x 105 (D) x 83 (H) mm |
| Weight | 1.2 kg |
| Chassis material | Extruded aluminum with heavy-duty metal |
| Operating temperature | -40–70 °C |
|---|
| Certifications | CEEN 61000-4-2EN 61000-4-3EN 61000-4-4FCCICES-003IEC 61000-4-5IEC 61000-4-6IEC 62368-1ULUL 62368-1 |
|---|
| Operating systems | Linux(optional)Windows(optional) |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
The order codes of this family: the sheet applies to all of them, the detail of each configuration is in the datasheet.
| Configuration (PN) |
|---|
| RCO-1000-X6425E-30-2P-P |
