RCO-1000-ASL-30Fanless mini computer with Intel Atom x7433RE/x7835RE and three EDGEBoost I/O slots
- Manufacturer
- Configurations
- 4 available configurations
RCO-1000-ASL-30 is a rugged embedded computer in extruded aluminium with a heavy duty metal structure, designed for industrial cabinets, IoT gateways and automation where there is no room for a ventilated system: 150 x 105 x 83 mm, 1.2 kg, wall mounting kit included.
The fanless design works from −40 to 70 °C with no moving parts, with humidity from 10 to 95 % non-condensing and storage from −40 to 85 °C. The power supply operates in AT and ATX mode, with OVP, OCP and reverse polarity protections, and adjustable ignition management through the optional IGN module.
Available configurations: RCO-1000-ASL-X7433RE-30-P and RCO-1000-ASL-X7835RE-30-P with power adapter, RCO-1000-ASL-X7433RE-30 and RCO-1000-ASL-X7835RE-30 without.
At a glance
- SODIMM DDR5 up to 16 GB
- Shock and vibration per MIL-STD-810H
- UL 62368-1 safety, 4th edition
- Optional Hailo-8 AI module
- Optional 5G on M.2 B-Key
Technical specifications
| Processor | Intel Atom® x7433RE 6M Cache(optional)Intel Atom® x7835RE 6M Cache(optional) |
|---|---|
| Chipset | SoC |
| Graphics | Intel® UHD Graphics |
| AI module | Hailo-8(optional) |
| Memory | 1× SODIMM DDR5 262-pin 4800 MT/s |
|---|---|
| RAM type | DDR5 |
| Maximum RAM | 16 GB |
| Storage | 1× Internal 2.5" SATA HDD Bay (support H=9.5 mm) |
|---|
| Video outputs | 1× HDMI 1.4b (Resolution up to 3840x2160 @ 30 Hz)1× DP, 1× DIO(optional)1× HDMI, 1× DIO(optional) |
|---|
| Ethernet ports | 2.5 GbE1: Intel I226 (Support Wake-on-LAN and PXE) |
|---|---|
| USB ports | 3× USB 3.2 Gen 2 (10 Gbps) |
| Serial interfaces | 2× RS-232/422/4852× COM (Port 3,4)(optional)2× COM (Port 5,6)(optional) |
| Audio | 1× Mic-in, 1× Line-out |
| CAN bus | 2× CAN 2.0 A/B 2-pin Internal headerCAN Bus, 1x/2× DB9, 2 Ch(optional) |
| Wireless | 5G(optional)4G/LTE(optional) |
|---|
| Expansion | 1× M.2 (B Key, 2242 / 3042 / 3052) for storage/4G/5G Module1-Port DP 1.4 and DIO (4 in / 4 out, Isolated)(optional)1-Port HDMI 2.0 and DIO (4 in / 4 out, Isolated)(optional)4-Port USB module with USB hub(optional)2-Port COM module with Super I/O Chipset(optional) |
|---|
| Mounting | VESA Mount(optional)DIN Rail Mount(optional)Wall Mount(optional) |
|---|---|
| Dimensions | 150 (W) x 105 (D) x 83 (H) |
| Weight | 1.2 kg |
| Operating temperature | -40–70 °C |
|---|---|
| Storage temperature | -40–85 °C |
| Certifications | EN 61000-4-2UL 62368-1ICES-003FCCCEUKCAIEC 62368-1 |
|---|
| Operating systems | Linux(optional)Windows(optional) |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
Columns show only what changes between configurations: the rest of the sheet applies to the whole family.
| Configuration (PN) | Ordering variants |
|---|---|
| RCO-1000-ASL-X7433RE-30 | Fanless Mini Computer with Intel® x7433RE Processor, 3× EBIO |
| RCO-1000-ASL-X7433RE-30-P | — |
| RCO-1000-ASL-X7835RE-30 | Fanless Mini Computer with Intel® x7835RE Processor, 3× EBIO |
| RCO-1000-ASL-X7835RE-30-P | — |
