Industrial Workstations with Motherboard
GO-A32-WSRack workstation with seven full length slots and three fans
- Manufacturer
- Configurations
- 1 available configurations
GO-A32 is an industrial rack cabinet workstation for heavily expanded systems: seven full length slots take even the longest boards, the ones that do not fit in a compact chassis.
The steel chassis takes motherboards for Pentium 4, dual Xeon, Athlon 64 and dual Opteron, with two 5.25 inch bays, a 3.5 inch floppy and PATA, SATA, SCSI320, Multilane SATA or SAS interfaces. Three 92 mm fans manage the airflow and the front is closed by two doors with a lock. The chassis measures 483 × 133 × 650 mm.
At a glance
- Storage: PATA, SATA, SCSI320, Multilane SATA or SAS
- Motherboard form factor: ATX
- Number of slots: 7
- Mounting: Rack Mount
- Cooling: Fan (active)
Technical specifications
| Storage | PATA, SATA, SCSI320, Multilane SATA or SAS2x 5.25" CD-ROM & 1x 3.5" FDD &(3.5-SATA) |
|---|
| Motherboard form factor | ATXE-ATX |
|---|---|
| Number of slots | 7 |
| PSU power | 500–650 W(optional) |
|---|
| Rack units | 3 |
|---|---|
| Mounting | Rack Mount |
| Chassis color | Nero, beige o altri colori su richiesta |
| Dimensions | Chassis 3U - 483 x 133 x 650 mm |
| Chassis material | Acciaio pre-zincato |
| Front panel buttons | Power On/Off Momentary (Pushbutton) e System Reset |
| Cooling | Fan (active) |
|---|
| Storage temperature | -20–70 |
|---|---|
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Compatible boards
Family configurations
The order codes of this family: the sheet applies to all of them, the detail of each configuration is in the datasheet.
| Configuration (PN) |
|---|
| GO-A32-SAS-PF |
