Industrial Workstations with Motherboard
GOI-115-WS1U rack chassis with a redundant power supply up to 750 W
- Manufacturer
GOI-115 is a one rack unit chassis in electrogalvanized cold rolled steel, arranged for the X11SCW-F and X12STW-F motherboards and intended for equipment installed in a cabinet.
The bays are configured in one of two ways: a 5.25" optical drive with a floppy and two 3.5" drives, or two optical drives with a floppy. The rear bay accepts a redundant power supply, expansion runs on one horizontal PCI slot served by a riser board and the front LEDs signal power, drive activity and the status of the two network interfaces.
At a glance
- Storage: 1 x 5.25” | Or 1x DVD slim +1 x 3.5″
- Number of slots: 2
- Expansion: 1x PCIe x16 + 1x PCIe x8
- Mounting: Rack Mount
- Cooling: Fan (active)
Technical specifications
| Storage | 1 x 5.25” | Or 1x DVD slim +1 x 3.5″ |
|---|
| Other I/O | Front: Removable panel with captive screws, 2 x USB 2.0 |
|---|
| Number of slots | 2 |
|---|
| Expansion | 1x PCIe x16 + 1x PCIe x8 |
|---|
| PSU power | 750 W(optional) |
|---|
| Rack units | 1 |
|---|---|
| Mounting | Rack Mount |
| Chassis color | Black |
| Dimensions | Chassis 1U - 483 x 44 x 540 mm |
| Chassis material | Pre-galvanized steel |
| Front panel buttons | Power On/Off, System Reset |
| Cooling | Fan (active) |
|---|---|
| Air filter | 1 front-removable washable air filter |
| Storage temperature | -20–70 |
|---|---|
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
