Industrial Workstations with Motherboard
GO-4F3ATX-WS4U rack chassis with front I/O and a rear power supply
- Manufacturer
GO-4F3ATXR-PF is a four rack unit chassis in cold rolled steel, intended for the motherboards that carry the I/O on the front panel and for the power supply installed at the rear.
The internal bays take a 5.25" optical drive and two 3.5" drives. The rear bay accepts a single ATX power supply or a mini redundant one, while the front carries two USB ports and the power and drive activity LEDs. The standard finish is black, with beige and custom colors available.
At a glance
- Storage: 1 x 5.25” + 2 x 3.5”
- Motherboard form factor: E-ATX
- Mounting: Rack Mount
- Cooling: Fan (active)
- Operating temperature: 0~50
Technical specifications
| Storage | 1 x 5.25” + 2 x 3.5” |
|---|
| Other I/O | Fronte: 2 x USB Alloggiamento per 7 bracket full height |
|---|
| Motherboard form factor | E-ATX |
|---|
| PSU power | 500–700 W(optional) |
|---|
| Rack units | 4 |
|---|---|
| Mounting | Rack Mount |
| Chassis color | Nero, beige o altri colori su richiesta |
| Dimensions | Chassis 4U - 483 x 177 x 447 mm |
| Chassis material | Acciaio pre-zincato |
| Front panel buttons | Power On/Off e System Reset |
| Cooling | Fan (active) |
|---|
| Storage temperature | -20–70 |
|---|---|
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
