DLAP-3100-CFP12Barebone edge AI platform with an MXM GPU slot
- Manufacturer
DLAP-3100-CFP12 is an industrial PC for processing on the machine and on the production line. The chassis is prepared both for installation in a rack cabinet and for wall mounting, so as to follow the space available in the field rather than impose it.
The chipset is declared in the H310 and Q370 versions and the memory accepts error correcting modules, a usual condition where the system stays on for entire shifts. The cellular module covers the data link where the wired network does not reach, while the front reset button allows a direct restart in the field. The declared storage temperature runs from -20 to 70 °C.
At a glance
- Memory: Non-ECC DDR4 2666/2400MHz, 2× SODIMM, fino a 64GB (secondo CPU)
- RAM type: DDR4
- Maximum RAM: 64 GB
- ECC support: Yes
- Storage: USB2.0 y d C ef N a x u 1 lt) PCIex4 or SATA
Technical specifications
| Chipset | H310Q370 |
|---|---|
| Graphics | Info only |
| Memory | Non-ECC DDR4 2666/2400MHz, 2× SODIMM, fino a 64GB (secondo CPU)Boot Service Data Specifies type of memory to useHDMI DDR4 non-ECC Socket ChannelB DP CN |
|---|---|
| RAM type | DDR4 |
| Maximum RAM | 64 GB |
| ECC support | Yes |
| Storage | USB2.0 y d C ef N a x u 1 lt) PCIex4 or SATA2× 2.5" SATA III (vani esterni), 1× SATA III via M.2 B-Key(SATA 6Gb/s) |
|---|
| Video outputs | 6× DisplayPort (2 da CPU, 4 da MXM) |
|---|
| Ethernet ports | 1× GbE (Intel® i219-LM)3x GbE (Intel® i210-AT) |
|---|---|
| USB ports | 4× USB 3.2 Gen1 x14× USB 2.0 |
| Serial interfaces | 1× RS-232/422/4851× RS-232 |
| Audio | Option 3: Line-in, L/R speaker-out (6W + 6W)(optional)Mic-in, L/R speaker-out (6W + 6W)(optional)Option 2: Mic-in, L/R speaker-out (6W + 6W)(optional) |
| Digital I/O | Default: w/o DIO Option: 1x DI/DO with 4 in, 4 out Note: Optional DIO, Audio and TPM 2.0 must be chosen together |
| Other I/O | Push to reset the system. |
| Wireless | 4G/LTE |
|---|
| AC/DC input | DC |
|---|---|
| Power input | DC V |
| Mounting | Wall Mount(optional) |
|---|---|
| Dimensions | 235 × 75 × 182 mm |
| Operating temperature | 0–50 °C |
|---|---|
| Storage temperature | -20–70 °C |
| Certifications | CEFCCUL |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
