DLAP-3000ADLINK edge AI computer with Intel CPU and DDR4 ECC memory
- Manufacturer
DLAP-3000 is an x86 class ADLINK edge AI platform: it collects and analyzes production data in the plant, where Windows or Linux applications are needed alongside inference workloads.
The processor is chosen when ordering, between Intel Celeron or Pentium and 8th or 9th generation Intel Core i3, i5 or i7, on an H310 or Q370 chipset. The declared operating systems are Linux and Windows 10 IoT.
At a glance
- CPU generation: 8th gen (Coffee Lake)
- Processor: 8th/9th Gen Intel® Core™ i7/i5/i3, Celeron® processor
- RAM type: DDR4
- Maximum RAM: 64 GB
- ECC support: No
Technical specifications
| CPU generation | 8th gen (Coffee Lake)9th gen (Coffee Lake-R) |
|---|---|
| Processor | 8th/9th Gen Intel® Core™ i7/i5/i3, Celeron® processor |
| Chipset | H310Q370 |
| Graphics | Info onlyADLINK MXM Graphics module support (Type A/B, up to 120W) |
| RAM type | DDR4 |
|---|---|
| Maximum RAM | 64 GB |
| ECC support | No |
| Storage | 2× 2.5" SATA III, external bays(SATA 6Gb/s) |
|---|
| Video outputs | 6× DisplayPort (2 da CPU, 4 da MXM)4096x2304@60Hz(DisplayPort) |
|---|
| Ethernet ports | 1× GbE (Intel® i219-LM) |
|---|---|
| USB ports | 4× USB 2.04× USB 3.2 Gen1 x1 |
| Serial interfaces | 1× RS-2321× RS-232/422/485 |
| Audio | Option 2: Mic-in, L/R speaker-out (6W + 6W)(optional)Option 3: Line-in, L/R speaker-out (6W + 6W)(optional) |
| Digital I/O | Default: w/o DIO; Optional: 1x DI/DO with 4 in, 4 out |
| Other I/O | Push to reset the system. |
| Wireless | 4G/LTE |
|---|
| AC/DC input | DC |
|---|---|
| Supply voltage | 1.5–5 V |
| Mounting | Wall Mount(optional) |
|---|---|
| Dimensions | 235 × 75 × 182 mm |
| Operating temperature | 0–50 °C |
|---|---|
| Storage temperature | -20–70 °C |
| Certifications | CEFCCUL |
|---|
| Operating systems | LinuxWindows 10 IoT |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
