APCI-1710-24VPCI function-module board with 24 V encoder inputs
- Manufacturer
The function modules are reprogrammable: the same board can implement 32-bit counters, position measurement from incremental encoders and other digital functions, adapting to the application without changing hardware.
The 24 V inputs accept the differential counter signals together with the index and the error signal, with input frequency up to 1 MHz. Galvanic separation towards the field side is 1000 V and the creepage distance meets IEC 61010-1.
At a glance
- Channels: 4 channel
- Isolation voltage: 1000 V (optoisolatori)
- Board function: Analog and digital I/O
- Architecture standard: PCI
- Supply voltage: 5 V DC
Technical specifications
| Digital I/O | 28× isolated DI 24 V + 4× DO 24 V high-side (500 mA); 28× TTL I/O |
|---|---|
| Connectors | D-Sub(male · front) |
| Other I/O | PCI bus clock divided by 4 (only APCI-/CPCI-1710) or 10 MHz from the quartz oscillator on the board, can be selected through software |
| Channels | 4 channel |
|---|---|
| Counter | 4 programmable function modules; 32 bit counters; inputs max 1 MHz (24 V) |
| Acquisition specifications | 24 V high-side outputs (ground-referenced load), 500 mA/channel24 V inputs: UH 19–30 V, UL max 15 V (24 V signals only)(logic levels)RDS(on) resistance of the outputs 0.4 Ω max(misc) |
| Isolation | Yes(opto) |
| Isolation voltage | 1000 V (optoisolatori) |
| Board function | Analog and digital I/O |
|---|---|
| Architecture standard | PCI |
| Bus interface | PCI 32 bit, 5 V (spec. 2.1 PCISIG) |
| Supply voltage | 5 V DC |
|---|---|
| Power consumption | 5.75(+5 V) |
| Dimensions | 179 × 99 mm |
|---|
| Operating temperature | 0–60 °C |
|---|
| Certifications | IEC 61010-1 |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
