APCIe-1032PCI Express board with 32 opto-isolated digital inputs
- Manufacturer
Splitting the inputs into blocks with separate grounds makes it possible to read groups of signals coming from different cabinets without creating ground loops between sections of the plant.
The inputs are protected against fast transients, electrostatic discharge and high-frequency noise, as well as against overvoltage and over-temperature. Optical isolation towards the field side is rated 1000 V.
At a glance
- Channels: 32 channel
- Board function: Analog and digital I/O
- Architecture standard: PCI Express
- Operating temperature: 0–60 °C
Technical specifications
| Digital I/O | 32× DI isolati (24 V, 16 interrompibili) |
|---|---|
| Connectors | D-Sub(male · front) |
| Channels | 32 channel |
|---|---|
| Acquisition specifications | Ingressi 24 V nominali (0–30 V): corrente 2 mA; frequenza max 5 kHz(range)Timer 12-bit (1×, programmabile 1–4095 µs/ms/s)(misc) |
| Isolation | Yes |
| Isolation voltage | 1000 V (optoisolatori, PC→periferia)(ch sys) |
| I/O protection | ESD |
| Board function | Analog and digital I/O |
|---|---|
| Architecture standard | PCI Express |
| Bus interface | PCI Express 1.0a (slot x1/x4/x8/x16) |
| Dimensions | 149 × 99 mm |
|---|---|
| Weight | 0.141 kg |
| Operating temperature | 0–60 °C |
|---|---|
| Storage temperature | -25–70 °C |
| Certifications | IEC 61010-1 |
|---|
| Operating systems | WindowsLinux |
|---|---|
| Driver & SDK | www.addi-data.com/drivers |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
