APCIe-040PCIe board with changeover relays and multiple watchdogs
- Manufacturer
The timers are programmable from 2 µs up to 255 minutes with a selectable time base, so the same board covers short process watches and long plant supervision.
The changeover contacts switch up to 200 VDC or 200 VAC, while an onboard temperature sensor allows the inner environment of the computer to be monitored. Isolation towards the field side is rated 1000 V.
At a glance
- Watchdog: Yes
- Channels: 8 channel
- Acquisition specifications: 7 canali trigger/ingressi gate (24 V)
- Isolation voltage: 1000 V (optoisolatori)
- Board function: Analog and digital I/O
Technical specifications
| Watchdog | Yes |
|---|
| Digital I/O | 8× relè in scambio (200 VDC/VAC, 2 A) + 7× DI isolati (24 V) |
|---|---|
| Connectors | D-Sub(male · front) |
| Channels | 8 channel |
|---|---|
| Counter | 7 watchdog/timer (8 bit, 2 µs–255 min) |
| Acquisition specifications | 7 canali trigger/ingressi gate (24 V)8 relè con contatto in scambio: max 200 VDC/VAC, 2 A, 60 W; response ≤4 ms(output)Sensore di temperatura onboard: -35~85 °C, risoluzione 8 bit(misc)Ingressi digitali 24 V: corrente 5–8 mA(range)±1 °C (sensore di temperatura)(accuracy) |
| Isolation | Yes |
| Isolation voltage | 1000 V (optoisolatori) |
| Board function | Analog and digital I/O |
|---|---|
| Architecture standard | PCI Express |
| Bus interface | PCI Express 1.0a (slot x1/x4/x8/x16) |
| Power input | DC V |
|---|
| Dimensions | 149 × 99 mm |
|---|---|
| Weight | 0.116 kg |
| Operating temperature | 0–60 °C |
|---|---|
| Storage temperature | -25–70 °C |
| Operating systems | WindowsLinux |
|---|---|
| Driver & SDK | www.addi-data.com/drivers |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
