ABOX-5000Fanless embedded computer for vehicle and railway applications, EN 50155 certified
- Manufacturer
- Configurations
- 3 available configurations
ABOX-5000 is a family of fanless embedded computers for on-board vehicle and on-machine installations: aluminum wall mount chassis, 9–36 VDC power input with ignition management and EN 50155, E-Mark and MIL-STD-810 certifications.
It is configured to order with 6th/7th generation Intel quad-core CPUs (Core i3/i5/i7 or Xeon E3), up to 32 GB of DDR4, four GbE ports, four isolated serial ports and two hot-swap SATA bays; the G and G1 variants add a dedicated AMD or NVIDIA GPU.
At a glance
- CPU generation: 6th gen (Skylake)
- RAM type: DDR4
- Maximum RAM: 32 GB
- Storage: 2× bay 2.5″ SATA (HDD/SSD), RAID 0/1/5
- USB ports: 4× USB 3.0
Technical specifications
| CPU generation | 6th gen (Skylake)7th gen (Kaby Lake)(variant ABOX-5000P) |
|---|---|
| Processor | Intel Core i5-6500TE (6M cache, 2.3~3.3 GHz)(optional)Intel Xeon E3-1268L v5 (8M cache, 2.4~3.4 GHz)(optional)Intel Core i7-6700TE (8M cache, 2.4~3.4 GHz)(optional)Intel Core i3-6100TE (4M cache, 2.7 GHz)(optional) |
| Chipset | Q170C236 |
| Graphics | Intel® HD Graphics 530 |
| Memory | 2× SO-DIMM DDR4-2133, max 32 GB(2133 MHz) |
|---|---|
| RAM type | DDR4 |
| Maximum RAM | 32 GB |
| Storage | 2× bay 2.5″ SATA (HDD/SSD), RAID 0/1/5 |
|---|
| Video outputs | 2× DisplayPort (max 4096×2304 @60 Hz) + 1× VGA (max 1920×1200 @60 Hz), triple display indipendente |
|---|
| Ethernet ports | 4× GbE RJ45 (3× Intel i210-AT + 1× Intel i219-LM, PXE/WoL)4× PoE RJ45 (15.4 W per porta)(optional · variant ABOX-5000P) |
|---|---|
| USB ports | 4× USB 3.0 |
| Serial interfaces | 4× RS-232/422/485, isolate 1,5 kVrms (auto direction control) |
| Audio | 1× line-out1× mic-in (line-in opzionale)(optional) |
| Digital I/O | 8× GPI + 4× GPO, isolati 1,5 kVrms(in)8× GPI + 4× GPO, isolati 1,5 kVrms(out) |
| PoE | 4× PoE (15.4 W)(optional · variant ABOX-5000P) |
| Wireless | 4G/LTE3G/WCDMA |
|---|
| Expansion | 3× Mini-PCIe full-size + 1× half-size (2× SIM per 3G/LTE) |
|---|
| AC/DC input | DC |
|---|---|
| Power input | 9–36 V |
| Ignition management | Power off Delay Time Setting by BIOS and Software |
| Battery / UPS | Internal Battery Kit for 10 Mins Operating(optional) |
| Mounting | Wall Mount |
|---|---|
| Dimensions | 226 × 79 × 240 mm |
| Weight | 3.86 kg |
| Chassis material | alluminio |
| Cooling | Fanless |
|---|---|
| Operating temperature | -40–70 °C |
| Storage temperature | -40–80 °C |
| Certified market sectors | RailwayAutomotive |
|---|---|
| Certifications | FCCEN 50155E-MarkMIL-STD-810CE |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
Columns show only what changes between configurations: the rest of the sheet applies to the whole family.
| Configuration (PN) | Graphics |
|---|---|
| ABOX-5000G | AMD Radeon E9260 |
| ABOX-5000G1 | NVIDIA GeForce GTX 1050 |
| ABOX-5000G2 | — |
