Industrial Workstations with PICMG1.3 Backplane [PCIe/PCI]
GOI-200-WS132U 19″ rack industrial workstation on a PICMG 1.3 backplane for SHB boards
- Manufacturer
GOI-200-WS13 is the industrial workstation on a PICMG 1.3 backplane configuration of the GOMA GOI-200 chassis, 2U 19″ rack. The chassis measures 483 × 88 × 450 mm. The rear provides 6 expansion slots.
The boards validated for this version include ROBO-8115VG2AR, for Intel Xeon, Core, Pentium and Celeron processors. The front carries a removable, washable air filter.
At a glance
- Architecture standard: PICMG 1.3
- Number of slots: 6
- Mounting: Rack Mount
- Cooling: Fan (active)
- Operating temperature: 0~50
Technical specifications
| Other I/O | Fronte: Porta drives con viti imperdibili, connettore PS2, e USB · Retro: Alloggiamento per 6 bracket full height |
|---|
| Architecture standard | PICMG 1.3 |
|---|---|
| Number of slots | 6 |
| Rack units | 2 |
|---|---|
| Mounting | Rack Mount |
| Dimensions | Chassis 2U - 483 x 88 x 450 mm |
| Chassis material | Acciaio pre-zincato |
| Chassis color | Nero o altri colori su richiesta |
| Front panel buttons | Power On/Off e System Reset |
| Cooling | Fan (active) |
|---|---|
| Air filter | 1 filtro per l’aria lavabile |
| Humidity | 10–95 |
|---|---|
| Operating temperature | 0~50 |
| Storage temperature | -20–70 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
