Industrial PCs with PICMG1.3 Backplane [PCIe/PCI]
GO-608B-IPC13Wall-mount industrial PC on a PICMG 1.3 backplane for SHB boards
- Manufacturer
GO-608B-IPC13 is the industrial PC on a PICMG 1.3 backplane configuration of the GOMA GO-608B chassis, wall-mount. The chassis measures 330 × 175 × 418 mm. The rear provides 10 expansion slots.
The boards validated for this version include NuPRO-E43, NuPRO-E47, PCIE-Q370 and PCIE-Q470, for Intel Core, Pentium and Celeron processors. The front carries a removable, washable air filter.
At a glance
- Architecture standard: PICMG 1.3
- Number of slots: 10
- Mounting: Panel Mount
- Cooling: Fan (active)
- Operating temperature: 0~50
Technical specifications
| Other I/O | Fronte: 2 x USB + 1 connettore tastiera PS2 · Retro: Alloggiamento per 10 bracket full height e 4 x DB9 |
|---|
| Architecture standard | PICMG 1.3 |
|---|---|
| Number of slots | 10 |
| Dimensions | 330 x 175 x 418 mm |
|---|---|
| Mounting | Panel MountWall Mount |
| Chassis material | Acciaio pre-zincato |
| Chassis color | Beige |
| Front panel buttons | Power On/Off e System Reset |
| Other features | Barra di ritenzione schede |
| Cooling | Fan (active) |
|---|---|
| Air filter | 1 filtro per l’aria rimovibile dal fronte lavabile |
| Operating temperature | 0~50 |
|---|---|
| Humidity | 10–95 |
| Storage temperature | -20–70 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
