Industrial PCs with Motherboard
GO-B06A-IPCBook-mount box PC with a front 1U power supply, AC or DC
- Manufacturer
GO-B06A is an industrial enclosure in pre-galvanized steel for wall or benchtop mounting, with the 20 mm brackets supplied.
The chassis accepts a 12″ × 9.6″ motherboard with full height and full length boards on seven slots, and carries on the front the I/O shield, the brackets and the input of the 1U power supply, available in AC or DC. Three 80 mm PWM fans regulate the airflow; the power button integrates the LED and inside there is a 2.5″ bay.
At a glance
- Storage: 1x 2.5″ internal
- Motherboard form factor: ATX
- Number of slots: 7
- Expansion: 7 slot Full Height
- Supply voltage: 1U power supply unit - Front power input AC or DC version
Technical specifications
| Storage | 1x 2.5″ internal |
|---|---|
| Internal bays | 1 x 2.5" internal |
| Other I/O | Front: I/O shield motheboard and integrated card brackets |
|---|
| Motherboard form factor | ATX |
|---|---|
| Number of slots | 7 |
| Expansion | 7 slot Full Height |
|---|
| Supply voltage | 1U power supply unit - Front power input AC or DC version |
|---|
| Mounting | Wall Mount |
|---|---|
| Chassis material | Pre-galvanized steel |
| Chassis color | Black |
| Dimensions | 372(L) x 124.9(A) x 355(P) mm |
| Front panel buttons | Power On/Off with integrated LED |
| Cooling | Fan (active) |
|---|---|
| Storage temperature | -20–70 |
| Operating temperature | 0~50 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
