EGX-MXM-BW4000MXM Type B graphics module with NVIDIA RTX PRO 4000 Blackwell
- Manufacturer
EGX-MXM-BW4000 is an MXM 3.1 Type B graphics module with NVIDIA RTX PRO 4000 Blackwell, 16GB GDDR7 and PCIe Gen 4/5 x16 interface.
At a glance
- 7,680 CUDA cores
- 240 Tensor cores for inference
- 896GB/s memory bandwidth
- ECC memory support
Technical specifications
| FPGA / processing | 7,680 CUDA Cores, 240 Tensor Cores, 60 RT Cores |
|---|---|
| Graphics | NVIDIA RTX PRO 4000 Blackwell |
| Memory | 16GB GDDR7 |
|---|
| Architecture standard | MXM |
|---|---|
| Board function | GPU / Graphics |
| Bus interface | PCIe Gen 4/5 x16 |
| Dimensions | 82 (W) x 105 (D) x 4.8 (H) mm |
|---|
| Operating temperature | 0–55 °C-40–85 °C |
|---|
| Operating systems | WindowsLinux |
|---|
| Form factor | MXM Type B |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
