APCI-3110-812-bit PCI board with 8 analog inputs and 4 analog outputs
- Manufacturer
The inputs are programmed channel by channel across the available voltage scales and reach a conversion frequency of 200 kHz; the analog outputs cover the range from -10 to +10 V with 12-bit resolution.
Digital inputs and outputs at 24 V, twenty-four TTL lines, counters and watchdog complete the board. Optical isolation towards the field side is rated 1000 V on both the analog and the digital channels.
At a glance
- Watchdog: Yes
- Channels: 8
- ADC resolution: 12-bit bit
- Sampling rate: 200
- Analog input range: 0-5 V
Technical specifications
| Watchdog | Yes |
|---|
| Digital I/O | 4× DI 24 V isolati + 4× DO 24 V isolati + 24× TTL I/O |
|---|---|
| Connectors | D-Sub(male · front)N-pin connector(male) |
| Channels | 8 |
|---|---|
| Counter | 3 timer + 3 contatori, 16 bit |
| ADC resolution | 12-bit bit |
| Sampling rate | 200 |
| Analog input range | 0-5 V±10 V0-1 V0-2 V±5 V±2 V0-10 V±1 V |
| DAC resolution | 12-bit bit |
| Analog output range | ±10 V |
| Trigger modes | SoftwareInternal timerExternal digital trigger(24 V) |
| Acquisition specifications | 4 uscite analogiche isolate, 12 bit: ±10 V, ±5 mA max, setup 15 µs(output)Ingressi analogici: 0–10 V, ±10 V, 0–5 V, ±5 V, 0–2 V, ±2 V, 0–1 V, ±1 V; 0–20 mA opzionale (programmabili via software per canale)(range)Precisione uscite analogiche: 11 bit(accuracy)Guadagno PGA x1, x2, x5, x10 programmabile via software per canale(accuracy) |
| Isolation | Yes |
| Isolation voltage | 1000 V through opto-couplers from PC to peripheral(ch sys) |
| I/O protection | Overvoltage(± 40 V) |
| Board function | Analog and digital I/O |
|---|---|
| Architecture standard | PCI |
| Bus interface | PCI 32-bit 3.3/5V acc. to spec. 2.2 (PCISiG)Data to the PC through FIFO memory, Interrupt at EOC (End Of Conversion), DMA transfer at EOC |
| Power input | DC V |
|---|
| Dimensions | 175 × 99 mm |
|---|
| Operating temperature | 0–60 °C |
|---|
| Certifications | IEC 61010-1 |
|---|
| Driver & SDK | Through write/read commands |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
