PMC230A-8PMC module with eight 16-bit analog voltage outputs
- Manufacturer
PMC230A-8 is the eight channel configuration of the PMC analog output module: every channel has its own 16-bit D/A converter and the output ranges are chosen by jumper among ±5V, ±10V and 0 to 10V.
The declared operating temperature is 0 to 70°C and the consumption of the module is 1.2 W. It is used to generate analog references and commands from an embedded system in PMC form factor.
At a glance
- Architecture standard: PMC
- Board function: Analog and digital I/O
- Power consumption: 1.2 W
Technical specifications
| Acquisition specifications | Indefinite at 25°C(protection) |
|---|
| Architecture standard | PMC |
|---|---|
| Board function | Analog and digital I/O |
| Bus interface | 5V Compliant, 3.3V Tolerant |
| Power consumption | 1.2 W |
|---|
| Storage temperature | -55–100 °C |
|---|---|
| MTBF | 662291 h(MIL-HDBK-217F, notice 2) |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
