TANK-630-EHLFanless IEI embedded computer for wall or VESA bracket mounting
- Manufacturer
- Configurations
- 3 available configurations
TANK-630-EHL is a fanless IEI embedded computer for machine automation, quality control and on-plant stations: a 2.04 kg extruded aluminum chassis, with wall or VESA bracket mounting.
The platform is the quad-core Intel Celeron J6412 with DDR4 memory up to 32 GB (8 GB preinstalled); on board are three 2.5GbE ports, two HDMI 4K, RS-232/422/485 and RS-232 serial ports, 12-bit DIO on DB15 and three M.2 slots, with DC power input. Linux and Windows support.
At a glance
- CPU generation: Elkhart Lake
- Processor: Intel® Celeron® J6412 2.0 GHz (up to 2.6GHz, quad-core, TDP 10W)
- CPU TDP: 10 W
- RAM type: DDR4
- Maximum RAM: 32 GB
Technical specifications
| CPU generation | Elkhart Lake |
|---|---|
| Processor | Intel® Celeron® J6412 2.0 GHz (up to 2.6GHz, quad-core, TDP 10W) |
| Chipset | SoC |
| CPU TDP | 10 W |
| Memory | 2× SO-DIMM DDR4 3200 (8 GB pre-installati)(default)2× SO-DIMM DDR4 3200 MHz (8 GB pre-installati)(default) |
|---|---|
| RAM type | DDR4 |
| Maximum RAM | 32 GB |
| Storage | 1× 2.5" SATA 6Gb/s HDD/SSD bay |
|---|
| Video outputs | 2× HDMI 1.4b (fino a 4K @30Hz) |
|---|
| Ethernet ports | 3× 2.5 GbE (Intel I226-V) |
|---|---|
| USB ports | 4× USB 2.02× USB 3.2 Gen2 |
| Serial interfaces | 6× RS-232 (DB9)2× RS-232/422/485 con AFC (DB9) |
| Audio | 1× Line-out |
| Digital I/O | 1× DIO 12-bit (DB15)(bidir) |
| Other I/O | 1 x Power Button · 1 x Reset Button · 1 x AT/ATX Switch |
| Wireless | Wi-Fi(optional) |
|---|
| Expansion | 1× M.2 2230 A-key (PCIe Gen3 x1/USB 2.0)1× 2230 A-key (PCIe Gen3 x1/USB 2.0)(PCIe-x1)1× 2042/52/80 B-key (SATA/USB 2.0)(M.2)1× 2280 M-key (PCIe Gen3 x2)(PCIe-x2) |
|---|
| AC/DC input | DC |
|---|---|
| Power input | 12–28 V |
| Power consumption | 40.32 W |
| Mounting | Wall MountVESA Mount |
|---|---|
| Dimensions | 184 × 53 × 200.6 mm |
| Weight | 2.04 kg |
| Chassis material | alluminio(extruded) |
| Cooling | Fanless |
|---|---|
| Storage temperature | -20–70 °C |
| Certifications | UKCACEFCC |
|---|
| Operating systems | WindowsLinux |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
Columns show only what changes between configurations: the rest of the sheet applies to the whole family.
| Configuration (PN) | Video outputs | Ethernet ports | USB ports | Serial interfaces |
|---|---|---|---|---|
| TANK-630-EHL-JC-R10 | 2xHDMI | 3x2.5GbE Lan | 2xUSB 3.2, 4xUSB2.0 | 6xRS232, 2xRS-232/422/485 |
| TANK-630-EHL-W10IoT21-E-R13 | 2 x HDMI™ (up to 4K@30Hz) | Ethernet: 3 x 2.5 GbE by Intel® I225-V/I226-V controller | 2 x USB3.2 Gen24 x USB 2.0 | six RS-232 and two RS-232/422/4852 x RS-232/422/485 (DB-9)6 x RS-232 (DB-9) Digital I/O: 12-bit Digital I/O (DB15) |
| TANK-630-EHL-W11IoT24-E-R11 | 2 x HDMI™ (up to 4K@30Hz) | Ethernet: 3 x 2.5 GbE by Intel® I225-V/I226-V controller | 4 x USB 2.02 x USB3.2 Gen2 | 2 x RS-232/422/485 (DB-9)6 x RS-232 (DB-9) Digital I/O: 12-bit Digital I/O (DB15)six RS-232 and two RS-232/422/485 |
