MIL-TSN / MIL-10TSNMilitary TSN switch with zero-packet-loss FRER redundancy
- Manufacturer
At the core is a Xilinx UltraScale+ MPSoC with four 64-bit ARM Cortex-A53 CPUs, two Cortex-R5F, an ARM Mali GPU and a 16 nm UltraScale+ FPGA, alongside up to 4 GB of DDR4, 32 GB of eMMC and 512 Mb of QSPI.
Time distribution runs over IEEE 802.1AS, with optional Grand Master and clock bridging functions; security includes IEEE 802.1X and MACsec, with optional firewall and VPN. The equipment is qualified to MIL-STD-461 and MIL-STD-810, with certified enclosure, DO-160 Section 22, power compliant with MIL-STD-704F and MIL-STD-1275E and MIL-DTL-38999 connectors; declared MTBF is 200,000 hours and the product is ITAR free.
At a glance
- Serial interfaces: 1× RS-232 (Miscellaneous connector)
- Management: Managed
- Copper port speed: 10/100/1000 Gigabit Mbps
- Supply voltage: 28 V DC
- Power consumption: 20–35 W
Technical specifications
| FPGA / processing | Xilinx UltraScale + MPSoC device: 4x 64bit CPU ARM-Cortex-A53; 2x 32bit CPU ARM-Cortex-R5F; 1x GPU ARM-Mali 400MHz; 1x 16nm UltraScale+ FPGA |
|---|
| Serial interfaces | 1× RS-232 (Miscellaneous connector) |
|---|---|
| Digital I/O | 2× GPIO or PPS/IRIG-B input (Miscellaneous connector) |
| Connectors | RJ45 |
| Device type | Ethernet switch |
|---|---|
| Management | Managed |
| Copper port speed | 10/100/1000 Gigabit Mbps |
| Supply voltage | 28 V DC |
|---|---|
| Power consumption | 20–35 W |
| Dimensions | 220 × 98 × 155 mm |
|---|---|
| Weight | 3 kg |
| Cooling | Fanless |
|---|---|
| MTBF | 200000 h(GB) |
| Certifications | MIL-STD-1275MIL-STD-461MIL-STD-704MIL-STD-810 |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
