MIL-SR / MIL-10SRRugged military switch with optional zero-packet-loss HSR/PRP redundancy
- Manufacturer
Ports reach 26 Ethernet, configurable between 10/100/1000Base-T copper and 1GbE/10GbE fiber, plus one Ethernet service port and one RS-232 serial port on the Miscellaneous connector.
Layer 2 offers 802.1Q VLANs, 802.1p QoS, LLDP, port rate limiting and storm control; spanning tree redundancy covers STP, RSTP and MSTP. Layer 3 routing includes OSPF, RIP, BGPv4, EIGRP and VRRP; security integrates IEEE 802.1X and MACsec with optional firewall and VPN, synchronization follows IEEE 1588 PTPv2 as Transparent or Ordinary Clock and the sealed military enclosure takes 28 V power to MIL-STD-704 and MIL-STD-1275E.
At a glance
- Serial interfaces: 1× RS-232 (connettore Miscellaneous)
- Management: Managed
- Copper port speed: 10/100/1000 Gigabit Mbps
- Redundancy protocols: MSTP
- Power input: DC V
Technical specifications
| Serial interfaces | 1× RS-232 (connettore Miscellaneous) |
|---|---|
| Digital I/O | 2× GPIO o ingresso PPS/IRIG-B (connettore Miscellaneous) |
| Connectors | RJ45 |
| Device type | Ethernet switch |
|---|---|
| Management | Managed |
| Copper port speed | 10/100/1000 Gigabit Mbps |
| Redundancy protocols | MSTPRSTPHSR/PRP(optional) |
| Power input | DC V |
|---|---|
| Power consumption | 20–35 W |
| Dimensions | 220 × 98 × 155 mm |
|---|---|
| Weight | 3 kg |
| Cooling | Fanless |
|---|---|
| MTBF | 200000 h(GB) |
| Certifications | MIL-STD-704DO-160MIL-STD-1275MIL-STD-461 |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
