IES-3162GCManaged Fast/GbE switch with 2 fiber ports
- Manufacturer
IES-3162GC is a managed Ethernet switch with Fast/Gigabit copper ports and two 100/1000Base-X fiber ports, for industrial networks in environments with wide temperature swings and power between 12 and 48 V.
On the network side it provides 7.2 Gbps of switching bandwidth with 2.28 us latency and supports the MRP, MSTP, O-Chain, O-Ring and RSTP redundancy protocols with 30 ms ring recovery. EMC immunity covers the IEC 61000-4 tests (ESD, RS, EFT, Surge, CS, PFMF).
At a glance
- Fiber ports (SFP/FX): 2
- Fiber port speed: 100/1000Base-X
- Serial interfaces: RS-232 in RJ45 connector with console cable. 9600bps, 8, N, 1
- Management: Managed
- Copper port speed: 10/100 Fast
Technical specifications
| Copper ports (RJ45/M12) | 162 |
|---|---|
| Fiber ports (SFP/FX) | 2 |
| Fiber port speed | 100/1000Base-X |
| Serial interfaces | RS-232 in RJ45 connector with console cable. 9600bps, 8, N, 1 |
| Management | Managed |
|---|---|
| Copper port speed | 10/100 Fast10/100/1000 Gigabit |
| Redundancy protocols | MRPO-RingO-ChainRSTPMSTP |
| Ethernet standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Forwarding mode | Store-and-forward |
| Switching bandwidth | 7.2 Gbps |
| Switching latency | 2.28 us |
| Throughput | 5.357 Mpps |
| MAC table | 8192 address |
| Packet buffer | 1 Mbit |
| Priority queues | 4 queue |
| IGMP multicast groups | 1024 group |
| Ring recovery time | 30 ms |
| Power input | 12–48 V |
|---|---|
| Redundant input | Yes |
| Power consumption | 15 W |
| Alarm relay | Yes(1A@24VDC) |
| Mounting | DIN Rail Mount |
|---|---|
| Dimensions | 96.4 × 154 × 108.5 mm |
| Weight | 1.22 kg |
| Operating temperature | -40–75 °C |
|---|---|
| IP rating | IP30 |
| Storage temperature | -40–85 °C |
| Operating altitude | 2000 m |
| MTBF | 600504 h |
| Manufacturer warranty | 5 year |
| EMC (emission/immunity) | IEC 61000-4-4 EFTIEC 61000-4-5 SurgeIEC 61000-4-6 CSFCC Part 15BEN 55032CISPR 32IEC 61000-4-8 PFMFEN 55024EN 55035IEC 61000-4-2 ESDIEC 61000-4-3 RS |
|---|---|
| Electrical safety | EN 62368-1 |
| End of life (EOL) | 30/09/2026 |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
