IES-3164GP-LAManaged switch, 16 Fast + 4 fiber
- Manufacturer
IES-3164GP-LA is a managed Ethernet switch with 16 10/100 copper ports and 4 100/1000Base-X fiber ports, intended for industrial networks operating in environments with wide temperature swings and DIN-rail installation constraints.
The redundant 12~48 V power input with reverse-polarity protection and OCP maintains continuity when line faults occur. The store-and-forward forwarding mode introduces a switching latency of 10 µs, with a 4.1 Mbit packet buffer and a MAC table of up to 8192 addresses.
At a glance
- Fiber ports (SFP/FX): 4
- Fiber port speed: 100/1000Base-X
- Serial interfaces: RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1
- Management: Managed
- Copper port speed: 10/100 Fast
Technical specifications
| Copper ports (RJ45/M12) | 16 |
|---|---|
| Fiber ports (SFP/FX) | 4 |
| Fiber port speed | 100/1000Base-X |
| Connectors | Terminal block |
| Serial interfaces | RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1 |
| Management | Managed |
|---|---|
| Copper port speed | 10/100 Fast |
| Redundancy protocols | MSTPMRPO-RingO-ChainRSTP |
| Ethernet standards | IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Forwarding mode | Store-and-forward |
| Switching bandwidth | 11.2 Gbps |
| Switching latency | 10 us |
| MAC table | 8192 address |
| Jumbo frame | 9.6 KB |
| Packet buffer | 4.1 Mbit |
| Priority queues | 4 queue |
| Power input | 12–48 V |
|---|---|
| Redundant input | Yes |
| Power consumption | 10 W |
| Alarm relay | Yes(1A@24VDC) |
| Mounting | DIN Rail Mount |
|---|---|
| Dimensions | 76 × 145 × 125 mm |
| Weight | 1.073 kg |
| Operating temperature | -40–75 °C |
|---|---|
| IP rating | IP30 |
| Storage temperature | -40–85 °C |
| Manufacturer warranty | 5 year |
| EMC (emission/immunity) | IEC 61000-4-5 SurgeIEC 61000-4-6 CSIEC 61000-4-8 PFMFFCC Part 15BCISPR 32EN 55032EN 55035IEC 61000-4-2 ESDIEC 61000-4-3 RSIEC 61000-4-4 EFT |
|---|---|
| Electrical safety | EN 62368-1 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
