VME4283A4U VME microrack with a 400 W power supply, up to 7 slots
- Manufacturer
VME4283A is a 4U microrack for 6U VME boards, intended for 19″ rack cabinets and for fitting into an IntermeZo laboratory enclosure: aluminum alloy frame of 84TE with 282.9 mm depth, with telescopic slides on request.
The Elma backplane reaches 7 VME, VME64x or VXS slots, with automatic daisy-chains and provision for a rear transition module, served by a 400 W power supply; the 6U modules enter horizontally, air leaves at the rear and the declared envelope is 0 to +55 °C, IP20, shock 15g/11ms and vibration 1.5g between 5 and 200 Hz. GOMA configures it for the application.
At a glance
- Number of slots: 4 slot
- Expansion: Backplane Elma con daisy-chain automatiche e terminazioni passive per schede 6U · Backplane VME monolitico 3-7 slot · Backplane VME64x con P0, 4-7 slot · Backplane VXS 5 slot
- Power input: Alimentatore modulare 3U 8HP power input: 100-240VAC, 250W · Alimentatore modulare 3U 8HP power input: 36-72VDC, min 150W · Alimentatore modulare 3U 8HP power input: 18-36VDC, 250W V
- Mounting: Rack Mount
Technical specifications
| Number of slots | 4 slot7 slot6 slot5 slot3 slot |
|---|---|
| Expansion | Backplane Elma con daisy-chain automatiche e terminazioni passive per schede 6U · Backplane VME monolitico 3-7 slot · Backplane VME64x con P0, 4-7 slot · Backplane VXS 5 slot |
| Power input | Alimentatore modulare 3U 8HP power input: 100-240VAC, 250W · Alimentatore modulare 3U 8HP power input: 36-72VDC, min 150W · Alimentatore modulare 3U 8HP power input: 18-36VDC, 250W V |
|---|
| Rack units | 4 U |
|---|---|
| Mounting | Rack Mount |
| Dimensions | 4U 84TE 282.9 mm |
| Chassis material | Lega di Alluminio |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
