VME3303A3U VME microrack for 6U boards, backplane up to 5 slots
- Manufacturer
VME3303A is a 3U microrack for 6U VME boards, intended for 19″ rack cabinets and for fitting into an IntermeZo laboratory enclosure: aluminum alloy frame of 84TE with 302.9 mm depth, with telescopic slides on request.
The backplane reaches 5 VME or VME64x slots and the 3U 8HP modular power supply accepts 100-240 VAC for 250 W, or DC at 36-72 V or 18-36 V; the 6U modules are inserted horizontally, air leaves at the rear through an extraction fan, and the declared envelope is 0 to +55 °C, IP20, shock 15g/11ms and vibration 1.5g between 5 and 200 Hz. GOMA configures it for the application.
At a glance
- Number of slots: 3 slot
- Mounting: Rack Mount
Technical specifications
| Number of slots | 3 slot4 slot5 slot |
|---|---|
| Expansion | Elma backplane with automatic daisy-chains and passive terminations for 6U boards · Monolithic VME backplane 3-5 slots · VME64x backplane with P0, 4-5 slots · VME64x backplane without P0, 4-5 slots |
| Supply voltage | Modular 3U 8HP power supply unit power input: 100-240VAC, 250W · Modular 3U 8HP power supply unit power input: 36-72VDC, min 150W · Modular 3U 8HP power supply unit power input: 18-36VDC, 250W V |
|---|
| Rack units | 3 U |
|---|---|
| Mounting | Rack Mount |
| Dimensions | 3U 84TE 302,9 mm |
| Chassis material | Aluminum alloy |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
