Industrial Monitors

OP-X24Austin Hughes industrial monitor with an MTBF of 30000 h

Manufacturer

OP-X24 is an Austin Hughes industrial monitor from the OP-X series, intended for operator stations, panels and technical installations in industrial environments, where the display works in continuous service.

The distinctive trait is DC power input: the DC input accepts nominal voltages selectable among 12, 24, 48 or 125 V, for connection to the plant DC lines.

The OP-X24 family comprises several configurations on the same base; an example part number is OP-X24/DC12.

At a glance

  • Display size: 24 ″
  • Resolution: 1920x1200 WUXGA
  • Brightness: Up to 399 standard cd/m²
  • Video inputs: VGA
  • Contrast ratio: 1000:1

Technical specifications

Display size24 ″
Resolution1920x1200 WUXGA
BrightnessUp to 399 standard cd/m²
TouchscreenResistive(optional)
Video inputsVGA
Aspect ratio16:10
Contrast ratio1000:1

AC/DC inputACDC(optional)
Supply voltage100–240 V AC9–18 V DC(optional)18–36 V DC(optional)36–75 V DC(optional)66–160 V DC(optional)

MountingPanel MountVESA Mount
Dimensions617.4 × 423 × 80.6 mm
Weight9.8 kg
Chassis colorDark gray

Operating temperature0–50 °C
MTBF30000 h

CertificationsCEFCCUKCAWEEE (2012/19/UE)RoHS(3)

Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.

Family configurations

Columns show only what changes between configurations: the rest of the sheet applies to the whole family.

Configuration (PN)AC/DC inputSupply voltage(V)
OP-X24/DC12DC9–18 V DC
OP-X24/DC125DC66–160 V DC
OP-X24/DC24DC18–36 V DC
OP-X24/DC48DC36–75 V DC
OP-X24/TRBACDC100–240 V AC9–18 V DC18–36 V DC36–75 V DC66–160 V DC
