DM2-121E-HL-R1012.1" panel-mount monitor with PCAP touch and an IP65 front
- Manufacturer
DM2-121E-HL-R10 is an industrial panel-mount monitor with a 12.1" display and a capacitive (PCAP) touchscreen, intended for panel installation in production and automation environments where the front is exposed to dust and liquids.
The HL variant reaches a brightness of 1000 cd/m², suited to environments with intense lighting, and operates over the -20~60 °C temperature range. The backlight declares an MTBF of 50000 h.
At a glance
- Display size: 12.1 ″
- Brightness: 1000+ sunlight cd/m²
- Touchscreen: PCAP
- Video inputs: HDMI
- Contrast ratio: 1000:1
Technical specifications
| Display size | 12.1 ″ |
|---|---|
| Resolution | 1024x768 XGA(max) |
| Brightness | 1000+ sunlight cd/m² |
| Touchscreen | PCAP |
| Video inputs | HDMIVGA |
| Display colors | 16.2M |
| Touch points | 10-point Projected capacitive touch window (Anti-UV, Anti-glare Surface)(pcap) |
| Video outputs | 1× VGA (DB-15)1× HDMI1× DisplayPort1.2 |
| Viewing angle | 178°/178° |
| Contrast ratio | 1000:1 |
| Backlight MTBF | 50000 h |
| Touch controller | ilitek |
| USB ports | 4× USB 3.2 Gen1 Type-A (5V2A) (Lite without)1× USB 3.2 Gen1 Type-B |
|---|---|
| Audio | 1× Line out |
| Other I/O | 1× 3-pin terminal block |
| AC/DC input | DC |
|---|---|
| Power input | 9–36 V |
| Chassis color | Black + Silver |
|---|---|
| Cutout dimensions | 270.50 × 214.10 mm |
| Dimensions | 237.5 × 49.3 × 279.86 mm |
| IP rating | Front IP65 |
|---|---|
| Storage temperature | -20–70 °C |
| Operating temperature | -20–60 °C |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
