CPCI-A35353U CompactPCI Serial CPU blade with Xeon W / Core i7 processors
- Manufacturer
- Configurations
- 3 available configurations
ADLINK cPCI-A3535 is a CompactPCI Serial CPU blade in 3U 4HP/8HP format, based on Xeon / Core i7 processors and rated for a −40~70°C range. Front-panel Ethernet is available with M12 X-coded or RJ-45 connectors, while five SATA3.x channels with RAID support and onboard 3D NAND storage in SLC mode cover the storage side. Intel iAMT remote management is accessible from the front panel and TPM 2.0 is fitted onboard.
At a glance
- Front M12 X-coded or RJ-45 Ethernet
- Five SATA3.x with RAID support
- Intel iAMT remote management from front panel
- Onboard 3D NAND storage in SLC mode
- TPM 2.0 onboard
Technical specifications
| Processor | Intel® Core™ i7-11850HE(optional)Intel® Xeon® W-11555MLE(optional) |
|---|
| Memory | 2× DDR4 |
|---|---|
| ECC support | Up to 64GB DDR4-3200 ECC socketed memory via 2× SODIMM sockets |
| RAM type | DDR4(3200) |
| Storage | Onboard 3D NAND SLC mode, 80GB, 160GB · 5x SATA3.x with RAID support · 80GB 3D Nand flash SSD in SLC mode |
|---|
| Ethernet ports | Dual 2.5GbE M12 X-coded rugged ports or dual 1GbE RJ-45 ports |
|---|---|
| Serial interfaces | SMBUS / I2c |
| Other I/O | SGPIO Links to control SATA carrier LEDUSB 3.2, USB-C and RJ-45 iAMT front panel service ports |
| Board function | CPU / Processor |
|---|---|
| Form factor | 3U 4HP3U 8HP |
| Dimensions | 3U 4HP/8HP 160mm x 100mm (L x W) |
|---|
| Operating temperature | -40–70 °C |
|---|---|
| Storage temperature | -40–85 °C |
| Certifications | CEEN 50121EN 50124-1EN 50155EN 55024FCCUKCA |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
Family configurations
The order codes of this family: the sheet applies to all of them, the detail of each configuration is in the datasheet.
| Configuration (PN) |
|---|
| cPCI-A3535/11555MLE/M32/S80 |
| cPCI-A3535D/11555MRE/M64/S80 |
| cPCI-A3535RJ/11850HE/M16 |
