VPX7283E3NDesktop 7U OpenVPX microrack for 3U boards, dual power supply
- Manufacturer
VPX7283E3N is an OpenVPX microrack in 7U format for 3U/160 mm boards, conceived as a laboratory development platform: it sits on a table on its own feet, without a cabinet, and the chassis is in 2.5 mm aluminum alloy with Surtech 650 treatment.
The VITA 65 backplane carries 9 VPX 3U slots, the rear card guides accept 6U transition modules and the two 6U 8HP modular power supplies accept 100-240 VAC at 400 W each; air enters from the bottom and exits at the top. GOMA configures it for the application.
At a glance
- Number of slots: 9 slot
- Expansion: Backplane VPX 3U 9 slot
- Power input: 2 x Alimentatore modulare 6U 8HP power input: 100-240VAC, 400W · Presa di rete singola, IEC, C14, 250VAC, 6A V
- Mounting: Desktop / Stand
Technical specifications
| Number of slots | 9 slot |
|---|---|
| Expansion | Backplane VPX 3U 9 slot |
| Power input | 2 x Alimentatore modulare 6U 8HP power input: 100-240VAC, 400W · Presa di rete singola, IEC, C14, 250VAC, 6A V |
|---|
| Dimensions | 7U 84TE 283 mm |
|---|---|
| Rack units | 7 U |
| Mounting | Desktop / Stand |
| Chassis material | Lega di Alluminio, 2.5 mm |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
