VPX5283B3N5U OpenVPX microrack for 3U boards with 3U transition modules
- Manufacturer
VPX5283B3N is an OpenVPX microrack in 5U format for 3U boards, used where high processing capacity is required in a small footprint and under critical operating conditions.
The extra height over the 4U leaves room for ventilation and power supply without changing the pitch of the 3U modules. GOMA configures it for the application.
At a glance
- Number of slots: 3 slot
- Expansion: 4 x Backplane 3U, 12HP, 3 slot, Open VPX
- Power input: Predisposizione per: · 4 x alimentatore modulare 3U, 8HP · cablaggio doppio ingresso di alimentazione sui 4 backplane VPX V
- Mounting: Rack Mount
Technical specifications
| Number of slots | 3 slot |
|---|---|
| Expansion | 4 x Backplane 3U, 12HP, 3 slot, Open VPX |
| Power input | Predisposizione per: · 4 x alimentatore modulare 3U, 8HP · cablaggio doppio ingresso di alimentazione sui 4 backplane VPX V |
|---|
| Dimensions | 5U 84TE 283 mm |
|---|---|
| Rack units | 5 U |
| Mounting | Rack Mount |
| Chassis material | Lega di Alluminio, 2.5 mm |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
