NPN-2BXavier NX edge AI computer with a 384 core Volta GPU
- Manufacturer
NPN-2B is a wall mount ADLINK edge AI platform: it runs vision and analysis models locally, without sending the video streams to a central server.
The Jetson Xavier NX module carries a 6-core NVIDIA Carmel Arm CPU with LPDDR4x memory. The unit weighs 1.035 kg, accepts a direct current input from 8 to 20 V and declares a power draw of 15 W.
At a glance
- AI module: NVIDIA Jetson Xavier NX
- AI performance: 14 TOPS @10W
- CPU class: ARM Carmel
- Processor: 6-core NVIDIA Carmel ARM v8.2 64-bit CPU 6MB L2 + 4MB L3
- Memory: 8GB 128 bit LPDDR4x @ 1600MHz 51.2GB/s GB
Technical specifications
| AI module | NVIDIA Jetson Xavier NX |
|---|---|
| AI performance | 14 TOPS @10W21 TOPS @15W |
| CPU class | ARM Carmel |
| Processor | 6-core NVIDIA Carmel ARM v8.2 64-bit CPU 6MB L2 + 4MB L3 |
| Graphics | 384-core NVIDIA Volta GPU with 48 Tensor Cores |
| Tensor cores | 48 |
| CUDA cores | 384 |
| Memory | 8GB 128 bit LPDDR4x @ 1600MHz 51.2GB/s GB |
|---|---|
| RAM type | LPDDR4x |
| Storage | 1× M.2 M-Key 2242 (SSD NVMe)1× microSD (board-level, 32GB di default)16GB eMMC 5.1 (su modulo NV) |
|---|
| Video outputs | 1× HDMI 2.0 |
|---|
| Ethernet ports | 4× GbE |
|---|---|
| USB ports | 4× USB 3.1 Gen1 (Type-A, di cui 2 lockable) |
| Audio | 1× line-out stereo (jack 3,5 mm) |
| Expansion | 1× M.2 E-Key (Wi-Fi) |
|---|
| AC/DC input | DC |
|---|---|
| Power input | 8–20 V |
| Power consumption | 15 W |
| Battery / UPS | CR2032 3V Li VARTA battery |
| Mounting | Wall Mount |
|---|---|
| Dimensions | 140 × 63.3 × 110 mm |
| Weight | 1.035 kg |
| Operating temperature | -20–50 °C |
|---|---|
| Storage temperature | -40–85 °C |
| Certifications | FCCCE |
|---|
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
