IGPS-1411GTPAUnmanaged GbE switch with PoE and DNV certification for marine applications
- Manufacturer
IGPS-1411GTPA is an unmanaged Ethernet switch for industrial networks, with DIN-rail or wall mounting and a redundant power input. The combination of Gigabit copper ports and a fiber uplink makes it suited to installations where PoE devices have to coexist with optical connectivity.
DNV certification to IEC 60945 qualifies it for use on board marine installations. The extended -40~75°C operating range and the PoE budget allow remote devices to be powered in thermally demanding environments as well.
At a glance
- Fiber ports (SFP/FX): 1
- Fiber port speed: 100/1000Base-X
- PoE ports: 4
- PoE power budget: 120 W
- Management: Unmanaged
Technical specifications
| Copper ports (RJ45/M12) | 5 |
|---|---|
| Fiber ports (SFP/FX) | 1 |
| Fiber port speed | 100/1000Base-X |
| PoE ports | 4 |
| PoE power budget | 120 W |
| Management | Unmanaged |
|---|---|
| Copper port speed | 10/100/1000 Gigabit |
| Ethernet standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Forwarding mode | Store-and-forward |
| MAC table | 1024 address |
| Jumbo frame | 10 KB |
| Power input | 50–57 V |
|---|---|
| Redundant input | Yes |
| Power consumption | 6.2 W |
| Alarm relay | Yes(1A@24VDC) |
| Mounting | Wall MountDIN Rail Mount |
|---|---|
| Dimensions | 26.1 × 144.3 × 94.9 mm |
| Weight | 0.458 kg |
| Operating temperature | -40–75 °C |
|---|---|
| IP rating | IP30 |
| Storage temperature | -40–85 °C |
| MTBF | 916635 h |
| Manufacturer warranty | 5 year |
| Certified market sectors | Marine |
|---|---|
| Certifications | DNV / IEC 60945 |
| EMC (emission/immunity) | IEC 61000-4-6 CSIEC 61000-4-8 PFMFIEC 61000-4-4 EFTIEC 61000-4-3 RSIEC 61000-4-5 SurgeEN 55032CISPR 32IEC 61000-4-2 ESDEN 55024FCC Part 15B |
| Electrical safety | IEC 60950-1EN 60950-1 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
