IES-1041FX-SS-SCUnmanaged switch, 4 copper ports + 1 SC fiber
- Manufacturer
IES-1041FX-SS-SC is an unmanaged Ethernet switch on DIN-rail with four copper ports and one fiber optic port with an SC connector, for interconnecting devices in industrial settings and in automation cabinets.
E-Mark certified, it operates in the -40~75°C range and can be powered over 12~48 V with a redundant input, conditions suited to installation in vehicles and on mobile equipment. EMC compliance covers the IEC 61000-4 tests on ESD, EFT and surge.
At a glance
- Fiber ports (SFP/FX): 1
- Fiber mode: Single-mode
- Management: Unmanaged
- MAC table: 2048 address
- Power input: 12–48 V
Technical specifications
| Copper ports (RJ45/M12) | 4 |
|---|---|
| Fiber ports (SFP/FX) | 1 |
| Fiber mode | Single-mode |
| Fiber standard | 100Base-FX |
| Fiber connector | SC |
| Wavelength | 1310 nm |
| Optical power TX/RX | 0 dBm(saturation · max) |
| Management | Unmanaged |
|---|---|
| Ethernet standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Forwarding mode | Store-and-forward |
| MAC table | 2048 address |
| Power input | 12–48 V |
|---|---|
| Redundant input | Yes |
| Power consumption | 5 W |
| Alarm relay | Yes(1A@24VDC) |
| Mounting | DIN Rail Mount |
|---|---|
| Dimensions | 26.1 × 144.3 × 94.9 mm |
| Weight | 0.378 kg |
| Operating temperature | -40–75 °C |
|---|---|
| IP rating | IP30 |
| Storage temperature | -40–85 °C |
| MTBF | 668306 h |
| Manufacturer warranty | 5 year |
| Certifications | E-Mark |
|---|---|
| EMC (emission/immunity) | IEC 61000-4-6 CSIEC 61000-4-8 PFMFIEC 61000-4-3 RSIEC 61000-4-2 ESDEN 55024FCC Part 15BEN 55032CISPR 32IEC 61000-4-4 EFTIEC 61000-4-5 Surge |
| Electrical safety | IEC 60950-1EN 60950-1 |
Data extracted from the manufacturers' technical sheets: the official product spec sheet remains the reference for final confirmation.
