CPGS-9080-CManaged 3U CompactPCI Ethernet switch, 8 Gigabit ports, EN 50155

Manufacturer

CPGS-9080-C is a managed Ethernet switch with 8 Gigabit ports intended for industrial networks and rail transport applications, where EN 50155 compliance and operation at extreme temperatures are binding requirements.

The fabric offers a switching bandwidth of 16 Gbps with a latency of 7 µs in store-and-forward mode, a 4 Mbit packet buffer and an 8192 address MAC table. Ring redundancy reaches a recovery time of 30 ms; the 5 V supply integrates an alarm relay and protections against overload and reverse polarity.

At a glance

Serial interfaces: 1× porta console RS-232 (115200 8N1)
MAC table: 8192 address
Copper port speed: 10/100/1000 Gigabit
Redundancy protocols: RSTP
Ring recovery time: 30 ms

Request information Full specifications ↓

Technical specifications

Serial interfaces	1× porta console RS-232 (115200 8N1)Default Baud rate: 115200, 8, n, 1(console)
Alarm relay	Yes
Ethernet standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x
Forwarding mode	Store-and-forward
IGMP multicast groups	128 group
Jumbo frame	9.6 KB
MAC table	8192 address
Packet buffer	4 Mbit
Copper port speed	10/100/1000 Gigabit
Copper ports (RJ45/M12)	8
Priority queues	8 queue
Redundancy protocols	RSTPMRPO-ChainO-RingMSTP
Ring recovery time	30 ms
Management	Managed
Switching bandwidth	16 Gbps
Switching latency	7 us
Supported VLANs	4096 vlan

Board function	Switch / Fabric
Architecture standard	cPCI 3U

Power input	DC V
Power consumption	6.2 W

Dimensions	20 × 130.7 × 209 mm
Weight	0.224 kg

Operating temperature	-40–70 °C
Storage temperature	-40–85 °C
MTBF	792718 h(Telcordia SR-332)

Certifications	EN 50155
EMC (emission/immunity)	FCC Part 15BCISPR 32IEC 61000-4-6 CSIEC 61000-4-8 PFMFIEC 61000-4-3 RSIEC 61000-4-2 ESDEN 55024IEC 61000-4-4 EFTIEC 61000-4-5 Surge
Electrical safety	EN 60950-1
